Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43

Ask Lasest Price
Brand Name :	JTP
Model Number :	14B
Price :	negotiation
Payment Terms :	T/T or western Union
Supply Ability :	5000pcs per month
Delivery Time :	5~10days

Add to Cart

Product Details
Company Profile

Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43

Genuine Spare Parts 13101-58040 14B For Toyota Piston& Cylinder liner with Alfin U-43

SPECIFIIONS:

Model Number	14B
Car Make	for TOYOTA
Cylinder Number	4 cyl
Diameter	102 mm
Total Length	87 mm
Pin Diameter	32 mm
Combustion Chamber Diameter	43 mm
Engine Type	Diesel type

SHIPPINGA AND SERVICE :

Packaging	Carcon box, wooden box, or as customers' requirements
Shiping way	by express, by air,by sea
Principle	for small order, we can only accept 100% in asvance
	substanitial order 50% advanced payment can be accepted
	shipping at any port in China, depends on negotiation
Production time	after receiving the payment(usually takes 3 days),we prepare the goods for you
Delivery time	depends on the shipping way

Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43

REMARKS:

1, Advanced technology, superb quality, reliability and honesty, satisfactory service

2, Reasonable price.

3, Considerate after-sales service.

4, Safe and fair cooperation with us.

5, We strictly adhere to OEM quality. Same quality and service in domestic and overseas markets.

PISTON TYPES

Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43

Piston skirt and crown

Consist of a steel piston head and an aluminium piston skirt which have a moveable connection to each other via the piston pin. Due to great strength and low wear and tear, it is possible to achieve low exhaust emission values for diesel engines that are subjected to particularly high loads.

Piston comes with bushes
In order to make it possible to increase the loads to which the pin boss can be subjected, this piston has pin boss bushes that are made of a special material

Alfin Pistons
Alfin is inserted within the ring grooves when casting. Alfin is made of special austenitic cast iron. It is tightly bonded metallically to piston body and counteracts the wear in the top or second ring groove.

Cooling channel piston
Cooling channel piston effectively reduce piston body working and groove land temperature under high temperature working condition.

PISTON SURFACE TREATMENT

Piston with Tin coating
Tin is coated by exectroanalysis or heat dipping at thickness between 0.001 and 0.003mm. Tin is characterized as soft and oil-friendly which improves running-in efficiency of piston and liner.

Pistons with Phosphating
The phosphating is aimed to improve initial running-in performance. The phosphating layer is easy to wear off and helpful to improve running-in.

Piston roof anodizing
The piston roof is anodized by electrobath, forming thin layer of Al O . This treatment will improve heat resistance, heat conductivity and anticorrosion, it helps prevent piston roof burn-up.

Graphipe printing and spratyed at piston skirt
Graphite is characterized as good lubriing, which helps lubricant adhering to coating surface.

Related Products.

MATERIAL:

Piston: ZL109 Aluminum Alloy, Alloy cast iron, ZL108 Aluminum Alloy

Piston Ring: Cast iron, Alloy, Steel

Cylinder Liner Material: Boron-containing Alloy Cast Iron, steel

Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43

ALSO BUSINESS ENGINE PARTS AS FOLLOW:

1.Piston/piston ring/piston pin/Cylinder Liner

2.Engine bearing/valve/guide/seat/thrust/gasket set

3.Gasket head/ cylinder head/ cylinder block/ cylinder liner

4.Crankshaft/camshaft/con rod/

5.Fuel pump/ oil pump/water pump

6.Starter/ generator/alternator

7.Injector/turbocharger

PRODUCT RANGE:

OEM No.	Model	CYL DIA	*ODL**
13101-10033	1E	70.5	18 60
13101-11050	2E	73	18 60
13101-11081	3E	73	18 60
13101-11101	4E	74	18 59
13101-11160	5E	74	18 59
13101-15020	3A	77.5	18 61
13101-16010	4A	81	18 61
13101-15040	5AF	78.7	20 60
	8A	78.7	20 60
13101-14050	8AFE	78.7	20 59
13101-16090	4AF	81	18 61
13101-16160	4AFE	81	20 61
13101-72010	2Y	86	22 66
13101-73010	3Y	86	22 66
13101-73030	4Y	91	22 66
13101-44011	5R	88	22 75
	5A/5AFE	87.8	18 60
13101-24011	3K	75	18 61
13101-13030	5K	80.5	18 61
13101-31020	12R	80.5	20 66
13101-35010	22R	92	22 75
13101-35032	22RE	92	22 75
13101-74130 13101-03030	5S	87	22 66
	COROLLA	84.8	21 60
13101-22020	1ZZFE	79	20 50
13101-78201	1DZ	86	27 68
13101-75010	1RZ	86	24 61
13101-75050	2RZ	95	24 70
13101-64120 13101-64122	2C	86	27 58
13101-54010	L OLD	90	27 74
13101-54090	2LT	92	29 74
13101-54060	2L	92	27 74
13101-54070	2L NEW	92	27 70
13101-54100	3L	96	29 74
13101-54101	3L-AL	96	29 74
13101-54170	5L	99.5	29 74
13101-58021	13B	102	34 84
1310-58040	14B	102	32 72
13103-30020	1KD	96
13101-30031 13101-30030	2KD	92	34 65
	2KD NEW
	1TR
	2TR
	1HZ	94	26 66
13101-37071	2ZR-FE	80.5	20 50
13101-61010	2F	96
13101-61030	3F	94
13101-64090	2C	86
13101-22020	1ZZFE	79	18 54
13101-21040	2NZ	75
13101-BZ100	BZ100	72	18 54
13101-BZ030	BZ030	72	18 54
13101-06040	7K	80.5	20 56
13101-06050	7K-2	80.5	20 56
13105-56030	B NEW	95	29 79

13101-66020	1FZ-FE	100

OUR ADVANTAGE:

1. High quality and competitive price.

2. Long life span, good sales-after service.

3. 100% new, strict inspection & test.

4. Standard export packing.

5. One year quality warranty.

6. Have strong stock, small order is acceptable

7. Various kinds are selectable with different car models.

8. Improve power and increase torque

9. Improve fuel economy and reduce fuel consumption

10. Reduce waste emissions and reduce environmental pollution

OUR FACTORY :

Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43

OUR PISTON SPECIFIION
Common Materials	Aluminum Alloy (lighter in weight and higher thermal conductivity); Senior Cast Iron (heavier in weight, greater strength and resistance to wear); Heat-resisting Steel, Hypereutectic Al-Si Alloy, Hypoeutectic Al-Si Alloy, Eutectic Al-Si Alloy, Multi-Cast Iron and Ductile-Cast Iron etc;
Piston Process	Casting, Forging, Melted Metal Squeezing;
Characteristics	Germany, advanced technique & wear proof & high temperature resistant etc.
Piston Types	Solid Skirt Pistons, Shim Type Pistons, Strut Type Pistons, Ring Carrier Pistons, Strut with Ring Carrier Type Pistons, Keystone Groove Pistons, Oil Cooled Pistons;
Different Treatment	Phosphating, Top Oxidization, Top Molybdenium Disulfide, Sn(tin)Plated on Skirt, Graphite on Skirt, Alfin, Double Alfin, None Alfin, Steel Pieces, Drilling, Oil-cooling Channel, Three or Four Ring Grooves, Ceramic Spraying and Hard Iron Plating etc;

ENGINE PISTON PICTURE AS BELOW:

Genuine Spare Parts 13101-58040 14B For Toyota Piston & Cylinder Liner With Alfin U-43
